雙組份打膠機流速慢或直接打不出膠來的原因
為了更好的使用打膠機進行工作，相關的問題應該多來了解，比如
雙組份打膠機流速慢或直接打不出膠來的原因有哪些呢？下面小編為您簡單講解一番。
In order to better use the glue dispenser for work, we should learn more about relevant problems. For example, what are the reasons for the slow flow rate of two-component glue dispenser or the direct failure to produce glue? Here's a brief explanation.
打膠機流速慢：
Slow flow rate of sealant applicator:
1）B組分有雜質：B組份在生產、運輸或儲存過程中如果操作不當或者存放不好，與空氣接觸易產生顆粒。
1) Impurities in component B: if component B is improperly operated or stored during production, transportation or storage, it is easy to produce particles when contacting with air.
2）工人施工不當：
2) Improper construction by workers:
①更換B組分時需要先排氣，排出來的B組分堆積在壓盤上，由于B組分壓盤只有一根桿，在往下壓的過程中會不斷晃動，壓盤上固化的B組分會掉入新桶內。固化的B組分經壓力后會分散成小顆粒，導致堵槍;②混合器和過濾網沒有經常清理;
① When replacing component B, it is necessary to exhaust first. The discharged component B is stacked on the pressure plate. Since the component B pressure plate has only one rod, it will shake continuously during the downward pressure process, and the solidified component B on the pressure plate will fall into the new barrel. The solidified component B will disperse into small particles after pressure, resulting in gun plugging; ② The mixer and filter screen are not cleaned frequently;
打膠機不出膠：
Glue does not come out of the gluing machine:
1，檢查氣源是否在0.60.8Mpa之間；
1. Check whether the air source is between 0.6 and 0.8Mpa;
2，檢查觸摸屏中編輯功能菜單中的密封不使用是否打開；
2. Check whether the seal is opened in the edit function menu of the touch screen;
3，檢查氣動開關是否阻塞；
3. Check whether the pneumatic switch is blocked;
4，檢查黑膠氣動開關與電磁閥動作是否正常；
4. Check whether the black glue pneumatic switch and solenoid valve operate normally;
5，檢查比例泵上的智能壓力表是否報警，范圍在7-35Mpa；
5. Check whether the intelligent pressure gauge on the proportional pump alarms, and the range is 7-35Mpa;
6，檢查液壓站是否有壓力，如無壓力：1）清洗比例溢流閥2）檢查比例控制器是否通電或松動；
6. Check whether there is pressure in the hydraulic station. If there is no pressure: 1) Clean the proportional overflow valve; 2) Check whether the proportional controller is energized or loose;
7，清洗時是否能出白膠，如不出再檢查313膠管、旋轉接頭是否阻塞；
7. Check whether white glue can be released during cleaning, and if not, check whether 313 rubber tube and rotary joint are blocked;
8，檢查一組比例泵下限傳感器IB233是否有信號，檢查二組比例泵IB407是否有信號；
8. Check whether there is signal from lower limit sensor IB233 of one group of proportional pumps and whether there is signal from IB407 of two groups of proportional pumps;
9，手動檢查掃描儀數值是否有正常。
9. Manually check whether the scanner value is normal.
What's wrong with the slow flow rate of the two-component glue dispenser or the direct failure to make glue? These conditions are indispensable. You can examine these aspects one by one. More information about the glue dispenser can be found on our website at any time http://www.dongwulife.com.cn Consult!
